    3051 Rosemount Differential Pressure Transmitter Emerson 4-20mA Original Pressure Transducer

    Ask Lasest Price
    Price :
    Brand Name : Rosemount
    Model Number : 3051CD/3051TG/3051CG/3051TG
    Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram
    Supply Ability : 3000 Piece/Pieces per Month
    • Product Details
    • Company Profile

    3051 Rosemount Differential Pressure Transmitter Emerson 4-20mA Original Pressure Transducer

    3051 Rosemount Differential Pressure Transmitter Emerson 4-20mA Original Pressure Transducer
    Product Description
    Pressure Transmitter Confidently measure pressure and level with the Rosemount 3051 In-Line Pressure Transmitter. Engineered for 10-year installed stability and 0.04% of span accuracy, this industry-leading pressure transmitter provides you with the information necessary to run, control and monitor processes. The Rosemount 3051 includes features that meet your pressure measurement needs, such as a wide rangedown and Power Advisory diagnostics and is suitable for safety installations.
    Range down Up to 150:1 Communication Protocol 4-20 mA HART, WirelessHART®, FOUNDATION fieldbus, Profibus, 1-5 V Low Power HART Measurement Range Up to 20000 psig (1378,95 bar) Gage, Up to 20000 psia (1378,95 bar) Absolute Process Wetted Material 316L SST, Alloy C-276 Diagnostics Basic Diagnostics, Loop Integrity Certifications/Approvals SIL 2/3 certified to IEC 61508 by an independent 3rd party, NSF, NACE®, hazardous location, see full specs for complete list of certifications
    Specification:
    Proof pressure
    ≤1.5X rated pressure or 110MPa which ever is less
    Pressure type
    Gauge, absolute ,sealed gauge
    Power Supply Effects
    ±0.001% /10V (12~42V DC)
    Static Pressure Effects
    ±(0.05%URL+0.075%Span)/10MPa
    Operating Temperature Range
    -20℃~80℃
    Storage Temperature Range
    -40℃~120℃
    Power supply
    15~30VDC
    Output signal
    4~20mA 0~10/20mA 0/1~5VDC
    Working Pressure Limits
    Maximum working pressure: 16MPa,25MPa,40MPa
    Sensor Body
    316L stainless steel
    UpTime
    < 15s
    Process Connection
    Flange with fixing thread 7/16-20 UNF and 1/4-18 NPT female thread on both sides
    Insulation resistance
    100MΩ,100VDC
    Protection
    IP65

    Features:

    Over 10 million Rosemount 3051 devices installed globally, providing reliable pressure readings in harsh environments. In-line gage and absolute pressure measurements support up to 20,000 psi (1378,95 bar) for pressure and level solutions. 10-year installed stability and 150:1 rangedown produce reliable measurements and wide application flexibility. Supports common protocols for integration in many host environments across many industries. Wide range of manifolds and remote seals are available – factory-assembled and leak-tested for easy installation. Local Operator Interface (LOI) enables quick commissioning and provides easy access to process and device information. SIL 2/3 certified to IEC 61508 (via 3rd party) and prior-use certificate of FMEDA data for safety installations. Loop Integrity diagnostics detect electrical loop issues for reduced downtime.
