YW-100B High Quality Pressure Gauge Equipped With Touch Buttons

The YW-100B series precision digital pressure gauge is a high-precision intelligent pressure measuring instrument developed and produced by our company in accordance with the latest national standards. The YW-100A series digital pressure gauge mainly consists of a pressure sensor and a signal processing circuit. Adopting imported pressure sensors with superior performance, it has advantages such as high accuracy, corrosion resistance, impact resistance, vibration resistance, low temperature drift, and high stability; The signal processing circuit is composed of the latest ultra-low power processors, signal processing chips, and power management chips. Powered by high-capacity high-performance lithium batteries, no external power supply is required. The instrument has a delicate, compact, and beautiful appearance, and is easy to operate.

Item	Value
Type	Digital Pressure Gauges
Place of Origin	China
	Shaanxi
Warranty	1 Year
Customized support	OEM, ODM, OBM
Brand Name	XINYIYB
Model Number	YW-100B
Material	304 stainless steel
Size	100mm
Weight	1 kg
Product Name	Axial digital pressure gauge
Output	4-20mA
Installation method	axial mount
Power supply	Non rechargeable lithium battery
Display digits	5-digit LCD display
Backlight features	With backlight
Measurement medium	Water pressure, air pressure, and oil pressure
Thread specification	M20*1.5

Characteristic

1.Touch the buttons with a button tone, effectively improving button usage.

2.Powered by a 4000mAh lithium battery (ER18505H), with a low-power design.

3.The battery is designed to be replaceable, making it convenient for customers to replace the battery themselves.

4.Wide temperature compensation, suitable for various harsh environments. Peak recording, unit conversion, and other functions are complete and convenient to use. Users can set their own collection rate, automatic shutdown time, button lock time, backlight automatic shutdown time and other parameters according to their habits.

5.11 pressure units can be converted, and the units that need to be converted can be set, and the units that are not commonly used can be turned off.

6.Added the function of restoring factory settings.

7.During the operation process, if the user makes a mistake, such as resetting under pressure or entering the setting interface for incorrect operation, etc. You can use this function to restore the pressure gauge to the factory calibrated data and settings.

8.To prevent touching other buttons, a lock key has been added.

9.During use, you can press the lock button, and a lock pattern will appear on the display screen, locking other touch keys without affecting compression and use. After use, it can be unlocked and turned off.
