YW-100GB Precision Explosion Proof Pressure Gauge 100mm 80mm With Display

Ask Lasest Price
Brand Name :	XINYIYB
Model Number :	YW-100GB
Price :	Discuss
Payment Terms :	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :	1000pcs/month
Delivery Time :	5-8 work days
MOQ :	1 PC

Add to Cart

Product Details
Company Profile

YW-100GB Precision Explosion Proof Pressure Gauge 100mm 80mm With Display

YW-100GB Precision Explosion Proof Digital Pressure Gauge With Display

YW-100GB Digital Pressure Gauge

YW-100GB digital pressure gauge imported sensor, superior performance, high accuracy, corrosion resistance, impact resistance, anti-vibration, high stability, etc.; signal processing circuitry using the latest ultra-low-power processors,signal processing and power management chip chips, using a large capacity,high performance lithium battery-powered, no external power supply. percentage using the digital display and analog display, intuitive readings, the product precision can reach 0.02 for ordinary pressure gauge, precision pressure gauge and pressure transmitter calibration and test, instead of themore traditional mechanical pointer pressure table-site measuring pressure.

Display mode	5-digit dynamic display and percentage display
Pressure unit	Pa ,kPa , MPa , psi , bar , mbar , mmH2O,mmHg ,inH2O ,inHg ,kg·f/cm
Overload pressure	150 %FS
Destruction pressure	200%FS
Power supply	4.2V rechargeable lithium battery
Working environment	Temperature: -20℃～50℃ Humidity: ≤85%RH Calibration reference environment: 20℃±2℃
Protection class	≧ IP66
Accuracy	0.05%FS 0.1%FS 0.2%FS 0.4%FS 0.5%FS
Material	Stainless Steel
Pressure range	-0.1~0~70~100MPa
Data storage	1 million

Product Features
● Touch the key, and with the key tone, effectively improve the use of keys.

● 4000mAh lithium battery power supply (ER18505H), low power consumption design.

● Battery replaceable design, convenient for customers to replace the battery.

● Wide temperature compensation, suitable for all kinds of harsh environments.

● Peak record, unit conversion and other functions are complete, easy to use.

● Users can set the collection rate, automatic shutdown time, key lock time, backlight automatic shutdown time and other parameters according to their habits.

●11 pressure unit conversion, and can be set to convert the unit, close the unit not used.

●Added restore factory Settings function. In the process of operation, if the user misoperates, such as under pressure, mistakenly reset, enter the setting interface, etc. This function can be used to restore the pressure gauge to the data and Settings of factory calibration.

● Lock keys have been added to prevent touching other keys. In use, you can press the lock button, a lock
pattern will appear on the display screen, lock other touch keys, and will not affect the press and use. After use, you can unlock and shut down.
